Discontinued

Product Information

Manufacturer Part Number: AP7811

Shipping Weight: 14.75 lbs

Description

Remote Management Capabilities
Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.

Local Current Monitoring Display
The aggregate current draw per power distribution unit is displayed on the unit via a digital display. The local digital display helps installers avoid overloaded circuits by providing a visible warning when the current draw is close to the maximum amperage draw of the strip. Alarm Thresholds Define alarm thresholds in order to avoid overloaded circuits. Network and visual alarms inform the user of possible problems. (Note: Only available on units with the current monitoring capabilities. Please see SKU specifications for availability)

Alarm Thresholds
Define alarm thresholds in order to avoid overloaded circuits. Network and visual alarms inform the user of possible problems. (Note: Only available on units with the current monitoring capabilities. Please see SKU specifications for availability)

Product Details

Product Type: PDU

Number of Output Connections: 12

Form Factor: 2U Rack-mountable

Current: 24 A Total Current Draw Per Phase

Input Receptacles: NEMA L6-30P

Output Receptacles: 12 x IEC 320-C13

Power Cord/Cable: 12 ft

Dimensions: 3.5" Height x 17.5" Width x 4.4" Depth

Product Line: Metered Rack

Input Voltage: 208 V AC

Manufacturer Website Address: www.apc.com

Standard Warranty: 2 Year

Output Voltage: 208 V AC

Height: 3.5"

Width: 17.5"

Depth: 4.4"

Cord Length: 12

Rack Height: 2U

Protection Type: Overload Protection

Package Contents

  • Metered Rack 30A PDU
  • Cord Retention Bracket(s)
  • Installation Guide
  • Rack Mounting Brackets
  • User Manual
